NOKIAN Tyres LOGGER KING LS-2

THE ULTIMATE WORKHORSE FOR THE FULL-TREE FORESTRY WORK

Find a dealer

For the hardest conditions and the biggest machinery

Nokian Tyres Logger King LS-2 is a new skidder tire made for the hardest conditions and the biggest machinery. It has the ruggedness to offer a long, trouble free service life as well as some clever features to speed up your daily work. Nokian Tyres Logger King LS-2 works with or without tracks. The tire features high groove bottom on the shoulder area. This gives more support to track paws and protects the tyre from damage.

Built to last

When working on distant sites, you don’t want any surprises. Nokian Tyres Logger King LS-2 tire is designed for a long, trouble-free service life in heavy skidder use. Its ultra-durable, high-strength multi-layer textile carcass with wide steel breakers offers an excellent puncture resistance – also in the shoulder area.

Advanced features

Nokian Tyres Logger King LS-2 tire features an aggressive tread design with excellent self-cleaning properties. This ensures good grip even on mud and wet surfaces. Its special rubber compound in the bead area minimizes rim slip and unique single wire bead construction makes on-site assembly easier.

Engineered for extreme

Nokian Tyres Logger King LS-2 is also available in Extreme version for the heaviest machinery and hardest conditions. Offering a load capacity up to 12 250 kg (27 000 lbs), the Extreme version is the ultimate tire for professional skidding. The Extreme version is available in sizes 30.5L-32 and 35.5L-32.

Read more: www.nokiantyres.com/loggerking-landingpage

Nokian Tyres Logger King LS-2 - The ultimate workhorse for the full-tree forestry work

Suitable for

Skidder

Suitable terrains

Forest Rough

Technical specifications

28L-26 20 165A6/161A8 Nokian Tyres Logger King LS-2 SF TL

LI / SSRecommended rimPermitted rimsTyre widthTyre diameterStatic loaded radiusTread depth
165A6 (161A8) DW25B - 720 mm28.4 in 1647 mm64.8 in 754 mm29.7 in 58 mm73/32 in
LI / SS 165A6 (161A8)
Recommended rim DW25B
Permitted rims -
Tyre width 720 mm28.4 in
Tyre diameter 1647 mm64.8 in
Static loaded radius 754 mm29.7 in
Tread depth 58 mm73/32 in
Rolling circumferenceSpeed radius indexMax inflation pressurePR
4945 mm194.7 in - 280 kPa41 psi 20
Rolling circumference 4945 mm194.7 in
Speed radius index -
Max inflation pressure 280 kPa41 psi
PR 20
Product code
T445615
Product code T445615

23.1-26 16 160A6/156A8 Nokian Tyres Logger King LS-2 SF TL

LI / SSRecommended rimPermitted rimsTyre widthTyre diameterStatic loaded radiusTread depth
160A6 (156A8) DW20B - 604 mm23.8 in 1623 mm63.9 in 749 mm29.5 in 54 mm68/32 in
LI / SS 160A6 (156A8)
Recommended rim DW20B
Permitted rims -
Tyre width 604 mm23.8 in
Tyre diameter 1623 mm63.9 in
Static loaded radius 749 mm29.5 in
Tread depth 54 mm68/32 in
Rolling circumferenceSpeed radius indexMax inflation pressurePR
4882 mm192.2 in - 280 kPa41 psi 16
Rolling circumference 4882 mm192.2 in
Speed radius index -
Max inflation pressure 280 kPa41 psi
PR 16
Product code
T445616
Product code T445616

24.5-32 20 169A6/167A8 Nokian Tyres Logger King LS-2 SF TL

LI / SSRecommended rimPermitted rimsTyre widthTyre diameterStatic loaded radiusTread depth
169A6 (167A8) DH21 - 637 mm25.1 in 1829 mm72 in 846 mm33.3 in 58 mm73/32 in
LI / SS 169A6 (167A8)
Recommended rim DH21
Permitted rims -
Tyre width 637 mm25.1 in
Tyre diameter 1829 mm72 in
Static loaded radius 846 mm33.3 in
Tread depth 58 mm73/32 in
Rolling circumferenceSpeed radius indexMax inflation pressurePR
5517 mm217.2 in - 310 kPa45 psi 20
Rolling circumference 5517 mm217.2 in
Speed radius index -
Max inflation pressure 310 kPa45 psi
PR 20
Product code
T445614
Product code T445614

30.5L-32 20 170A6/167A8 Nokian Tyres Logger King LS-2 SF TL

LI / SSRecommended rimPermitted rimsTyre widthTyre diameterStatic loaded radiusTread depth
170A6 (167A8) DH27 - 773 mm30.4 in 1843 mm72.6 in 853 mm33.6 in 67 mm84/32 in
LI / SS 170A6 (167A8)
Recommended rim DH27
Permitted rims -
Tyre width 773 mm30.4 in
Tyre diameter 1843 mm72.6 in
Static loaded radius 853 mm33.6 in
Tread depth 67 mm84/32 in
Rolling circumferenceSpeed radius indexMax inflation pressurePR
5542 mm218.2 in - 240 kPa35 psi 20
Rolling circumference 5542 mm218.2 in
Speed radius index -
Max inflation pressure 240 kPa35 psi
PR 20
Product code
T445621
Product code T445621
